Name: 160m Small Portable Water Well Drilling Rig Machine With 35HP Engine
Brand: Henan Rancheng Machinery Co., Ltd.
SKU: ار سي اس 260 سي
Price: 3500 USD
Availability: InStock

المنزل > المنتجات > آلة حفر الآبار المائية >

160m Small Portable Water Well Drilling Rig Machine With 35HP Engine

small portable water well drilling machine

35HP water well drilling rig

160m depth water well drilling machine

مكان المنشأ:

الصين

اسم العلامة التجارية:

Rancheng

إصدار الشهادات:

رقم الموديل:

ار سي اس 260 سي

اتصل بنا

طلب اقتباس

160m Small Portable Water Well Drilling Rig Machine With 35HP Engine

تفاصيل المنتج

حالة:

جديد

وزن:

4000 كجم

ضمان:

سنة واحدة

يكتب:

هيدروليكي

خدمة ما بعد البيع المقدمة:

خدمة 1,24/7 عبر الدردشة عبر الإنترنت والهاتف. 2 ، الدعم الفني مدى الحياة ومجاني. 3، الخدمة في الخارج

الاستخدام:

جهاز حفر آبار المياه

نوع الطاقة:

محرك الديزل

البعد (الطول * العرض * الارتفاع):

2300*1080*2000

الطاقة (ث):

25hp

عمق الحفر:

150

طلب:

ماء جيدا

إبراز:

small portable water well drilling machine

35HP water well drilling rig

160m depth water well drilling machine

شروط الدفع والشحن

الحد الأدنى لكمية

الأسعار

3500

تفاصيل التغليف

الصناديق الخشبية

وقت التسليم

7 أيام عمل

شروط الدفع

الاعتماد المستندي، تي/تي

منتجات ذات صلة

فيديو

اتصل الآن

وصف المنتج

Specifications

Model of drilling machine	RCS260C
Walking way	Rubber crawler mounted
Drilling machine overall dimension(mm)	230010802000
Weight of Drilling machine (kg)	1000
Drill rod diameter (mm)	Ø64
Drill rod length(mm)	1500
Rod change method	Full automatic screw thread
Drilling depth(m)	160
Diesel Motor Power (Hp/kw)	35HP /25.8KW
Drilling method	Percussive and rotating type
Drilling hole diameter(mm)	Within Ø 450mm
Stroke distance (mm)	2000
Hosting capacity (kg)	4000KG

RCS260C small hydraulic rubber crawler mounted water drilling rig

I. Applications

This water well drilling machine mainly apply to geothermal drilling, farm irrigation,house yard, gardens ,water well drilling and boring drilling etc,it can drill 70-450mm diameter , Max 160m depth,It also can be used in small building piling, like farmhouse or factory, the drilling diameter can reach 450mm ,it can apply to different stratum, such as sand,soil,clay,soft rock and so on.

160m Small Portable Water Well Drilling Rig Machine With 35HP Engine

small portable water well drilling machine

35HP water well drilling rig

160m depth water well drilling machine

small portable water well drilling machine

35HP water well drilling rig

160m depth water well drilling machine

Specifications

Model of drilling machine

RCS260C

Walking way

Rubber crawler mounted

Drilling machine overall dimension(mm)

2300*1080*2000

Weight of Drilling machine (kg)

1000

Drill rod diameter (mm)

Ø64

Drill rod length(mm)

1500

Rod change method

Full automatic screw thread

Drilling depth(m)

160

Diesel Motor Power (Hp/kw)

35HP /25.8KW

Drilling method

Percussive and rotating type

Drilling hole diameter(mm)

Within Ø 450mm

Stroke distance (mm)

2000

Hosting capacity (kg)

4000KG

RCS260C small hydraulic rubber crawler mounted water drilling rig

I. Applications

II. Features and Advantages

1. Light weight, energy saving.

2. Patented product, unique design and simple drilling structure;

3. Easy to transport and can learn how to handle the machine in short time;

4. Can drill through hard stratum, unless thick rock layer ;

5. One person operation, reduce the labor intensity ;

6. High efficiency and work fast;

7. Assure easily operation and long life service life.
